Vigilant Vision 7″ LED MONITOR (DSM7WGF)
The Vigilant Vision LED CCTV monitor has a screen size of 7in and used in security monitoring applications. It has a metal case and a glass front.
| Panel Type | 7″ LED Monitor |
| Case Type | Metal Case |
| Maximum Resolution | 800 (H) x 480 (V) |
| MTBF | 40,000 hrs |
| Active Display Area | 154.08 (H) × 85.92 (V) mm |
| Pixel Pitch | 0.0642 (H) × 0.179 (V) mm |
| Bezel Thickness | T: 20 mm L/R: 19.8 mm, B: 24.5 mm |
| Contrast Ratio | 500 : 1 Ratio |
| Brightness | 250 cd/ m² |
| Response Time | 25 m.sec (G to G) |
| Viewing Angle | 50 / 70 U / D 70 / 70° |
| Display Colours | 16.7 M |
| Video Synchronization | Yes |
| PC Compatibility | Yes |
| Aspect Ratio | 16 : 9 Ratio |
| VGA Auto Frequency correction | Yes |
| Speakers | Yes |
| Number of Speakers | 2 |
| Sound Demodulation | Stereo |
| Mute | Yes |
| Work Humidity | 0 % – 90 % |
| Work Temperature | 0 to +70 °C |
| Volume +/- Power On/Off | Yes |
